Load 120Kg Antirust Vibration Testing Machine Multifunctional
Application:
Electromagnetic vibration table is widely used in defense,
aviation, aerospace, communications, electronics, automobiles, home
appliances, and other industries. This type of equipment is used
for discovering the early faults, simulating the actual working
condition and the structure strength test, the product application
is wide, the application width is obvious, the test effect is
remarkable and reliable. Sine wave, FM, sweep, programmable,
frequency multiplier, logarithm, maximum acceleration, amplitude
modulation, time control, full function computer control, simple
fixed acceleration/fixed amplitude. Equipment through continuous
failure to run 3 months of testing, stable performance, reliable
quality.
The main performance:
1, the use of hydraulic lift, high pressure hydraulic brake free
fall impact machine to achieve vibration isolation system at
different impact pulse width impact characteristics of the test,
2, Adopting gas-liquid pressurization, powerful friction brake to
prevent secondary shock braking function;
3, with impact measuring instrument, single-channel data
acquisition, you can simultaneously two channels of acceleration
data measurement, storage, report printing, data callback, database
management and other functions.
4, can produce a wide range of half-sine pulse of any time.
5, can do the equivalent package drop test
Parameter:
| Vibration Testing Machine |
| Sine thrust | 600kgf |
| Random thrust | 600kgf |
| Impact thrust | 1200kgf
|
| Frequency Range | 5～2000Hz |
| Continued displacement | 51mm |
| The impact of displacement | 51mm |
| Maximum speed | 2m/s |
| Maximum acceleration | 981m/s2 |
| Moving coil diameter | Φ150mm |
| Allow eccentric moment | ＞190N.m |
| Load connection point | 6 piont |
| Equivalent mass of moving parts | 6kg |
| Countertops screw size (standard) | M8 |
| Screw layout table (diameter, circumference) | 8 on Φ100mm,8 on Φ,200mm. |
| Axial isolation frequency | ＜3Hz |
| Maximum load | 120Kg (customer request 45Kg) |
| Magnetic flux leakage | ＜1mT |
| Dimensions (without packaging)(L×W×H) | 1600mm×985mm×850mm |
| Vibration table Weight | 1850kg |
| Amplifier output | 8kVA |
| SNR | ＞65dB |
| System Protection | The entire power amplifier has: Grid overvoltage, undervoltage
power grid phase, logical failure, power module protection, power
module temperature, output overcurrent, output overvoltage, power
supply, displacement units, units body temperature, external
linkage, etc. protection circuit, when any fault occurs, turn off
the output, sound and light alarm. In addition to the above
protection, it also has a protective function RMS values of
tolerance protection, emergency stop devices, such as improving
running. |
| Rated output voltage | 120Vrms |
| Amplifier efficiency | ＞95% |
| Fan |
| Power | 0.75kW |
| Airflow | 0.3m3/s |
| Duct diameter | 120mm |
| Pressure | 0.048kgf/cm2 |
| Vertical extension table |
| Table size | 600mm×600mm |
| Equivalent mass | 23kg |
| Upper frequency | 2000Hz |
| Countertop Materials | Aluminium |
| Horizontal slide |
| Table size | 600mm×600mm |
| Thickness | 30mm |
| Countertops weight | 36kg |
| Frequency | 2000Hz |
| Bearing number | 1 |
| Bearing weight | 0.58kg |
| Connector Weight | 1.4kg |
| Maximum Load | 300kg |
| Countertop Materials | Aluminium |
