Laboratory Constant Temperature Humidity Chamber Incubator With LCD
Screen
Features:
1. Polished stainless-steel chamber, semicircular arcs at corners
for easy cleaning, and the space between the shelves in the chamber
is adjustable.
2. Large LCD screen
3. Latest PID controller
4. R134a refrigerant, imported compressor (DANFOSS)
5. RS485 connector are options which can connect computer to record
the parameters and the variations of temperature.(option)
6. There is a 25mm instruction connection hole on the left side of
the chamber for easy testing operation and temperature measurement.
How a Humidity Chamber Works:
The two factors that affect the stability of a product are
temperature and humidity, with humidity being the second most
damaging. It is for this reason that manufacturers test the effects
of humidity on their products since humidity fluctuations cause
expansion and contraction. The three basic methods for creating
artificial humidity are steam generators, atomizers, and water
baths. The AGREE form of test chamber is also used to test humidity
as well as temperature changes and vibrations.
Product introduction:
The new generation of constant temperature and humidity box sets
the company's many years of successful experience in cabinet
design. Based on the humanized design concept, we will try our best
to meet customer requirements in every detail from the actual needs
of customers, and provide customers with high-quality constant
temperature and humidity series product.
This test equipment prohibits: test and storage of samples of
flammable, explosive, and volatile substances
Test and storage of corrosive material samples
Testing or storage of biological samples
Test and storage of strong electromagnetic emission source samples
Specifications:
| Serial number | Volume | Inner size
D*W*H | Temperature range | Humidity range | Power 50hz/total rate (to be determined) |
| 01 | 80L | 400x400x 500 | 00~150°C
20~150°C
-40~150°C
- 50~150°C
-60~150°C
- 70~ 150°C
Selected according to test requirements | 30~ 98% | 220V/5 KW |
| 02 | 100L | 400x500x 500 | 220V/6KW |
| 03 | 150L | 500x500x 600 | 220V/6.5KW |
| 04 | 225L | 600x 500x750 | 220V/7KW |
| 05 | 408L | 800x 600x850 | 220V/7.5KW |
| 06 | 800L | 1000x800x1000 | 220V/7.5KW |
| 07 | 1000L | 1000x1000x1000 | 220V/8KW |
| Main indicators | a Temperature fluctuation: ≤±0.5°C, temperature uniformity: ≤+2°C
b Humidity error: ≤+2%/-3%R.H
c Cooling rate: 0.7~1°C/min, heating rate: 2~3°C/min
d Temperature change test chamber: cooling 3~5°C/min, heating
3~5/min
e Noise (dB)≤65 (all above are no-load)
|
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
