PCB / LED Humidity Automated Temperature Controlled Test Chamber OEM Thermal

Ask Lasest Price
Brand Name :	GSKA
Model Number :	Climatic Test Chamber
Certification :	CE SGS ROHS UL CE
Price :	Negotiate
Payment Terms :	T/T, L/C
Supply Ability :	100 Set / Sets per Month
Delivery Time :	10-60days after confirmed payment or by contract stipulation

Add to Cart

Product Details
Company Profile

PCB / LED Humidity Automated Temperature Controlled Test Chamber OEM Thermal

OEM Thermal Humidity Automated Temperature Control Test Chamber For PCB/LED

Customized size:

Inner door with operation hole (optional)

Entrance hole for test wire, Dia.50mm or 100mm

Sample Shelves, two layers

RS-232 or RS-485 communication Interface

Application:

high low temperature alternating test chamber is used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.

technical parameters:

Model	GSKA-80 (A~F)	GSKA-150 (A~F)		GSKA -225 (A~F)		GSKA -408 (A~F)		GSKA -800 (A~F)		GSKA -1000 (A~F)
Internal Dimensions WxHxD (mm)	400x500 x400	500x60 0x500		600x750 x500		600x850 x800		1000x1000 x800		1000x1000 x1000
External Dimensions WxHxD (mm)	950x1650 x950	1050x1750 x1050		1200x1900 x1150		1200x1950 x1350		1600x2000 x1450		1600x2100 x1450
Temperature Range	Low Temperature(A:25ºC B:0ºC C:-20ºC D:-40ºC E:-60ºC F:-70ºC) High Temperature 150ºC
Analytic Accuracy/Distribution Uniformity of Temperature	0.1ºC /±2.0ºC
Control Accuracy of Temperature	±0.5ºC
Temperature Rising / Falling Velocity	Temperature rising approx. 0.1~3.0ºC/min ; temperature falling approx. 0.1~1.5ºC/min; ( The Falling Speed Rate Min.1.5ºC per minute is a special optional condition)
Internal and External Material	Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or see cold-rolled steel with paint coated.
Insulation Material	Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials
Cooling System	Wind cooled or water cooled,single segment compressor for -40ºC, double segment compressor for -70ºC
Protection Devices	Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, Over-humidity and over-temperature protection switch, fuses, fault warning system
Optional Accessories	Inner door with operation hole(Optional), Recorder(optional),Dehumidifier
Compressor	French Tecumseh Brand,Germany Bizer Brand
Power	AC 220V, 1∮ 3 Lines,50/60HZ ; AC 380V ,3∮ 5 Lines,50/60HZ
Approx. Weight (Kg)	150		180		250		320		400		450

We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
