Electronic Stability Environment Climate Constant Temperature And
Humidity Test Chamber 100L
Product Features:
(1)The outer case is made up of SUS304 steel plate.CNC processing
molding,Beautiful design,Reacionless holder,easy operation
(2)Large LCD touching screen
(3)Adopt micro-computer temperature humidity controller.accuracy
and reliability
(4)Large watching window;floodlight,of which can keep inside of
chamber light;3 layers of vacuum glasses;can observe the status at
any time
(5)Individual temperature limitation alarm system;automatically cut
off when exceed temperature limitation;which can assure the safe
testing
(6)Equipped with the testing hole with the diameter of 50mm at the
both side of testing chamber.can be connected with outer power
cable or signal cable
(7)Adopt high quality fixed PU running wheel in the bottle of
machine
(8)New program temperature humidity chamber can save power more
than 45% compared than the traditional type.can save responding
time be around 50%.can deduct water consumption be around 80%
Test Chamber Design Features:
1. High performance and quiet operation (68 dBA)
2. Space-saving designed for flush installation to wall
3. Full thermal break around doorframe
4. One 50mm diameter cable port o left, with flexible silicone plug
5. Accurate wet/dry-bulb humidity measurement system for easy
maintain
Performance parameters:
Temperature| Model | G100 | G150 | G200 | G400 | PG800 | G1000 | | Inner chamber size W×H×D(cm) | 50×50×40 | 50×60×50 | 60×75×50 | 80×85×60 | 100×100×80 | 100×100×100 | | Exterior chamber size W×H×D(cm) | 78×157×105 | 78×167×115 | 88×185×115 | 108×195×125 | 128×210×145 | 128×210×165 | | Testing temperature range | 0ºC,-20ºC,-40ºC,-70ºC~180ºC | | Testing humidity range | 10%RH~98%RH | | Temp.humi.fluctuation | ±0.3ºC;±0.5%RH | | Temp.humi.uniformity | ±2ºC;±3% empty loading after stablize for 30mins ±2ºC;±3%RH | | Temp.humi.resolution | 0.01ºC;0.1%RH | | Heating&cooling time ºC/min | Heat-up:3ºC/min(average),cool-down:1ºC/min(average) | | Exterior chamber material | Cold rolled plate + Powder coating | | Interior chamber material | SUS#304 Stainless steel | | Insulation material | Rigid Polyurethane foam | | Circulation system | Centrifugal fan air circulation system | | Heating system | SUS# Stainless steel high-speed heater | | Humidification system | Electrothermal steam humidification | | Dehumidifying | ADP critical dew point cooling / dehumidifying method | | Refrigeration system | Finned evaporator + Air(Water) cooling condenser | | Controlling system | Touch screen controller | | Other components | Vacuum glass observation window | | Test hole(100mm) | | Controller status indicator | | View light | | Compartment shelf (2 freely adjustable) | | Safety protection device | Overheat protection circuit breaker | | Humidification system overheat protection | | Compressor overload protection | | Control system overload protection | | overload indicator | | Phase sequence protection | | Water shortage protection | | High voltage and low voltage protection | | Over temperature protection | | Water supply delay protection | | Fan overcurrent protection | | Power supply | AC 1ψ220V;3ψ380V 60/50Hz | | Customization service | Non-standard or special requirements are all welcome |
|
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
